FLUKE CLAMP METER

FLUKE 373 TRUE RMS AC CLAMP METER

MODEL # 373

Brand                   :  FLUKE
Model Number    :  373

FEATURES

Fluke 373 True RMS AC Clamp Meter does the job for any AC-only current measurement application



Fluke 373 True-RMS AC Clamp Meter is a great choice for AC-only current measurement situations. Featuring True RMS AC voltage and current measurements you can measure AC current to 600 A and AC voltage to 600V. The 373 also measures DC voltage to 600 V and resistance to 6000 Ω.



To make it even easier to use, the large, easy-to-read backlit display provides better visibility in dimly lit conditions. And the 373 automatically sets the correct measurement range based on the voltage present when you power up, so you do not need to move the switch while taking a measurement. When you put it all together, you’ll find the Fluke 373 offers everything you need, plus a little more.



  • A top performing True-RMS current clamp for AC-only current measurements to 600 A
  • Measures AC and DC voltage to 600 V
  • Measures resistance to 6000 Ω with continuity detection
  • Offers state of the art signal processing to provide stable readings even in noisy electrical environments



Other useful capabilities:

  • Provides True-RMS voltage and current measurements to accurately measure non-linear signals
  • Automatically selects a measurement range based on voltage present so you don’t need to change the switch positions while taking a measurement
  • Presents readings on a large, easy-to-read backlit display
  • Features CAT IV 300 V, CAT III 600 V safety ratings
  • Comes with a soft carrying case and three-year warranty
  • Runs on two AA alkaline batteries

SPECIFICATIONS

DOWNLOAD MORE INFO

AC Current

Range

600.0 A

Resolution

0.1 A

Accuracy

2 % ± 5 digits (48 – 62 Hz)

Crest Factor (50/60 Hz)

2.5 @ 600 A

AC Voltage

Range

600.0 V

Resolution

0.1 V

Accuracy

1.0 % ± 5 digits (48 – 62 Hz)

DC Voltage

Range

600.0 V

Resolution

0.1 V

Accuracy

1 % ± 5 digits

Resistance

40 Hz to 1 kHz

Range

600.0 Ω/6000 Ω

Resolution

0.1 Ω/1 Ω

Accuracy

1 % ± 5 digits

Continuity Beeper

30 Ω

Capacitance

Range

10.0 – 100.0 μF / 1000 μF

Resolution

0.1 μF/1 μF

Accuracy

1.9 % ± 2 digits

Mechanical Specifications

Size (L x W x H)

232 mm x 85 mm x 45 mm

Weight

370 g

Environmental Specifications

Operating Temperature

-10 °C to +50 °C

Storage Temp

-40 °C to +60 °C

Operating Humidity

Non condensing (< 10 °C)
≤ 90 % RH (at 10 °C to 30 °C)
≤ 75 % RH (at 30 °C to 40 °C)
≤ 45 % RH (at 40 °C to 50 °C)
(Without Condensation)

Operating Altitude

3000 meters

Storage Altitude

12,000 meters

EMI, EMC

Meets all applicable requirements in EN61326-1:2006

Temperature Coefficients

Add 0.1 x specified accuracy for each degree C above 28 °C or below 18 °C

Safety Compliance

ANSI/ISA S82.02.01:2004
CAN/CSA-C22.2 No. 61010-1-04
IEC/EN 61010-1:2001, 600V CAT III, 300V CAT IV
Pollution Degree 2
EN/IEC 61010-2-32:2002
EN/IEC 61010-031:2002/A1:2008

Agency Approvals

Batteries

2 AA, NEDA 15A, IEC LR6

WHAT'S INCLUDED?

Electrical Specifications

  • Coated instruction card

  • Safety information sheet

  • Soft carrying case

  • TL75 test leads

  • Two AA Alkaline batteries

  • AC only clamp meter

  • True RMS technology for enhanced accuracy

  • Measures AC voltage; continuity and resistance
